testo 552i - App-controlled wireless vacuum probe

Order-Nr. 0564 2552

Buy now

Identify vacuum quickly and easily by means of the graphical display in the App or on the digital manifold screen
Connects automatically via Bluetooth^® to the testo Smart App and digital manifolds
Exceptionally compact and reliable thanks to the robust, easy-to-handle housing with IP 54 protection class
Easy installation at any service port thanks to the integrated 45° angle

Use the testo 552i vacuum probe with Bluetooth to measure vacuum wirelessly with speed, ease and precision via just one service port – with no loss of refrigerant. The testo Smart App supports you with numerous intelligent features – for example, you can see the vacuum by simply glancing at the graphic illustration in the app or on the manifold’s display. Thanks to its robust, convenient housing and proven measuring technology, the vacuum probe is compact and reliable when carrying out your vacuum measurements on refrigeration and air conditioning systems and heat pumps.

Wireless measurement of the vacuum.

Details

Product Description

Wireless vacuum measurements via just one service port: The testo 552i app-controlled vacuum probe with Bluetooth enhances the Testo Smart Probes portfolio. It delivers reliable measurement results, is robust and easy to use – the vacuum probe provides optimum support for proper evacuation of refrigeration and air conditioning systems and heat pumps.

testo 552i - App-controlled wireless vacuum probe

For wireless, hose-free vacuum measurements on refrigeration and air conditioning systems and heat pumps using just only one service port – with no loss of refrigerant
testo Smart App – get an overview of everything: Detect vacuum quickly and easily via a graphic illustration in the app, with an alert in the event of any critical values, e.g. through vibration of the smartphone
Automatic connection via Bluetooth: The probe connects to the testo Smart App or to the appropriate digital manifold from Testo, e.g. testo 557s, testo 550s – so you can also read measured values conveniently on your manifold’s large display
Convenient, robust housing with protection class IP 54
Built-in 45° angle for easy installation at any service port
Continuously high performance in all conditions: You can depend on this wireless vacuum probe from Testo – it combines proven Testo quality with excellent robustness

Delivery Scope

App-controlled testo 552i wireless vacuum probe, including batteries and calibration protocol.

Related products

testo 570s - Digital manifold with 4-way valve block, Bluetooth and intelligent error analysis

Order-Nr. 0564 5701
- Long-term measurement with intelligent error analysis in the testo Smart App
- World's longest battery life of up to 360 hours with rechargeable battery (USB-C) and batteries
Details
testo 570s Smart Vacuum Kit - Smart digital manifold with wireless vacuum and clamp temperature probes

Order-Nr. 0564 5702
- Long-term measurement with intelligent error analysis in the testo Smart App
- World's longest battery life of up to 360 hours with rechargeable battery (USB-C) and batteries
Details
testo 570s Smart Vacuum Kit with clamp meter - Smart digital manifold with wireless vacuum and clamp temperature probes plus clamp meter

Order-Nr. 0564 5704
- Long-term measurement with intelligent error analysis in the testo Smart App
- World's longest battery life of up to 360 hours with rechargeable battery (USB-C) and batteries
Details
testo 570s Smart Vacuum Kit with filling hoses - Smart digital manifold with wireless vacuum and clamp temperature probes and 4-piece hose filling set

Order-Nr. 0564 5703
- Long-term measurement with intelligent error analysis in the testo Smart App
- World's longest battery life of up to 360 hours with rechargeable battery (USB-C) and batteries
Details
testo 550i - App-controlled digital manifold with Bluetooth and 2-way valve block

Order-Nr. 0564 2550
- All activities, from measurement through to documentation, using the testo Smart App on your Smartphone
- The smallest digital manifold on the market
Details
testo 550i Smart Kit - App-controlled digital manifold with wireless clamp temperature probes (NTC)

Order-Nr. 0564 3550
- All activities, from measurement through to documentation, using the App on your Smartphone
- The smallest digital manifold on the market
Details
testo 570s - Heat pump professional kit

Order-Nr. 0564 5002
- The testo 570s digital manifold with A3 compatibility, large graphic display, for maximum precision even at low pressure values, ideal for long-term and standard measurements, with intelligent error analysis in the testo Smart App
- Includes Bluetooth and 4-way valve block with 2 x testo 115i wireless clamp temperature probes and 1 x testo 552i wireless vacuum probe
Details

Technical Data

Absolute Pressure
Measuring range	0 to 26.66 mbar / 0 to 20000 micron
Accuracy	±10 micron + 10 % of mv (100 to 1000 micron) ±(1
Resolution	1 micron (0 to 1000 micron) / 10 micron (1000 to 2000 micron) / 100 micron (2000 to 5000 micron) /
Overload	absolute: 6.0 bar / 87 psi (relative: 5.0 bar / 72 psi)

General technical data
Weight	142 g
Dimensions	150 x 32 x 31 mm (LxWxH)
Operating temperature	-10 to +50 °C
Protection class	IP54
System requirements	requires iOS 13.0 or newer; requires Android 8.0 or newer; requires mobile end device with Bluetooth 4.2
Product colour	black/orange
Auto-off	10 min*
Battery type	3 AAA micro batteries
Battery life	39 h
Connection	7/16“ UNF
Interface	Bluetooth® 4.2
Storage temperature	-20 to +50 °C
